| Particular |
Specification |
Specification |
| Top Specification |
| Top design |
Four-piece adjustable top with round corners, 3/4" plywood deck3-layer padding
Bamboo wood underframe matches base |
Four-piece adjustable top with round corners, 3-layer foam, 3/4" plywood |
| Top adjustments |
Easy motorized adjustments of torso, knee and upper body sections, plus
the entire top can tilt to either end by using independent pedestal heights |
Easy motorized adjustments of torso, knee and upper body sections, plus
the entire top can tilt to either end by using independent pedestal heights |
| Back tilt angle |
0 to 60° |
0 to 60° |
| Knee tilt angle |
0 to 30° |
0 to 30° |
| Max tilt angle (entire top) |
0 to 15° |
0 to 15° |
| Top adjustment mechanism |
Two 24v DC, 5 amp max motor/actuators, UL recognized; powered through a
110v, 5 amp transformer |
Two 24v DC, 5 amp max motor/actuators, UL recognized; powered through a
110v, 5 amp transformer |
| Main lift mechanism |
Two 24v DC, 5 amp max motor/actuators for height adjustment of 26" to 34"
(powered through the same transformer as the top actuators) |
Two 24v DC, 5 amp max motor/actuators for height adjustment of 26" to 34"
(powered through the same transformer as the top actuators) |
| Controls |
8 button hand contol
2 button foot pedal |
8 button hand contol
2 button foot pedal |
| Standard size top |
30" x 73" |
30" x 73" |
| Foam |
2" firm bottom layer
1- 3/4" medium-density layer of urethane polymer, CFC-free foam |
2" firm bottom layer
1- 3/4" medium-density layer of urethane polymer, CFC-free foam |
| Polyester batting |
1/2" fluffy polyester Dacron top layer |
1/2" fluffy polyester Dacron top layer |
| Frame |
3/4" plywood frame reinforced for arm rests and face cradle |
3/4" plywood frame reinforced for arm rests and face cradle |
| Base&Frame |
| Base design |
Bamboo wood base features attractive geometric Art Deco elements
Anodized aluminum twin pedestals have bamboo trim inserts |
Carbon steel base/Contemporary design
White powder-coat finish with twin anodized aluminum pedestals |
| Leg recess, head end |
10" recess from ends of table |
10" recess from ends of table |
| Leg recess, foot end |
8" recess from ends of table |
8" recess from ends of table |
| Height range |
24.5"-32.5" |
24.5"-32.5" |
| Lifting weight |
Lifting weight capacity 650 lbs. |
Lifting weight capacity 650 lbs. |
| Capacity |
Static weight capacity 1000 lbs. |
Static weight capacity 1000 lbs. |
| Vinyl |
| UltraSoft-Touch Vinyl |
Lightly textured, super-soft PU vinyl, fabric backed |
Lightly textured, super-soft PU vinyl, fabric backed |
| Weights |
 |
 |
| Table weight |
275 lbs. |
 250 lbs. |
